BQ-500PSWG Asia Low Pressure Die Casting Machine for Large Aluminum Die Cast System Supplier

500kg, 800kg crucible type low pressure casting machine
Servo motor, high efficiecy and energy saving
Siemens PLC+HMI, high automation
High precision liquid surface pressure system, high qualified rate
Full hydraulic drive, stable and efficient
16 routes cooling, meet for most aluminum casting production, wide product practicability
Standard machine, short delivery time and good after-sale service

Parameter	Unit	BQ-200PWSG	BQ-500PWSG	BQ-800PWSG
Machine body
Fixed columns clearance	mm	1050*750	1650*1000	1750*1250
Max mold installation size	mm	1000*900	1100*1050	1400*1400
Distance between mobile and fixed platen	mm	450-900	450-1350	550-1800
Side cylinder stroke	mm	250	300	450
Opening force of upper cylinder	KN	122	177	245
Closing force of upper cylinder	KN	94	138	305
Opening force of side cylinder	KN	59	94	165
Closing force of side cylinder	KN	78	122	212
Ejection force	KN	122	177	305
Holding furnace
Furnace type		crucible	crucible or refractory
Capacity	KG	300	500	800
Power rate	KW	20	30	40
Temperature control accuracy	±℃	2	2-5
Furnace pressure	Bar	Max. 1.5 bar
Hydraulic pump station system
Motor type (Regulation or Servo)		optional
Motor power rate	KW	5.5	18.5	22
Hydraulic pressure	Bar	Min. 80 bar -max. 120 bar
Pump type (gear or plunger)		Optional
Cooling type		Air	Air or water	Water
Cooling water consumption	L/Min		40	50
Operation control system
PLC,HMI unit		Siemens
Operation method		Automatic
Main power voltage (380V 60HZ,400V 50HZ)	V,HZ	Optional
Auxiliary power voltage	V,HZ	24
Control cabinet cooling type		Fan	Fan or air conditioning
